Product Features
Electrical Properties: applicable to the UHF band RFID handheld terminal, such as the common antenna with a high gain, low standing wave and so on.
Mechanical Properties: small size, suitable for a variety of harsh environment.
Main Applications
Antenna is used for UHF Handheld reader.
Performance Specifications
Frequency Range: 865MHz～868MHz
Maximum VSWR: ≤1.3:1
Gain: > 4 dBi
Polarization: Circular Polarization
Beamwidth: 120º x 120º
Input impedance: 50 Ω
Antenna Connector: SMA (MMCX optional)
Physical specifications
Size: 60 mm×60 mm×11.6 mm Weight: 25g
Material: FR4
Operating temperature: -40℃~+ 85℃
Storage temperature: -40℃~+ 85℃
